W16 Engine (Bugatti)

Assembly : https://www.youtube.com/watch?v=KNmBc45omB0&feature=youtu.be

FR :
Moteur "fonctionnelle" : les piston bouge lors que l'on tourne l'arbre

Je recommande fortement l'utilisation de la colle cyanoacrylate pour monter le vilebrequin. (Attention colle extrêmement puissante ne pas en mettre trop, une petit goute suffit)

Ne pas oublier de mettre les bielles pendant le montage du vilebrequins

Post-traitement nécessaire (je recommande le faire pendant l'assemblage)

Moteur 16 cylindres en "W" -> W16
Le format W est utilisé que par le groupe "Volkswagen", en particulier dans sa filiale de Super-Car : "Bugatti" où est présent un W16 dans toute leurs voitures depuis la Veyron.




EN:
Engine 'functional': the piston moves when the shaft is turned

I highly recommend the use of cyanoacrylate glue to mount the crankshaft. (Warning, extremely powerful glue do not put too much, a small drop is enough)

Post-processing needed (I recommend doing this during assembly)

Do not forget to put the connecting rods during the assembly of the crankshafts

16-cylinder 'W' engine -> W16
The W format is only used by the 'Volkswagen' group, in particular in its Super-Car subsidiary: 'Bugatti' where a W16 is present in all their cars from the Veyron.


<html><head></head><body><h3 class="thing-component-header summary summary">Summary</h3>
<div><p>This is a remix of 11343 Single Cylinder Motor v2.0.</p>
<p>I increased the size so it can include two piston rings.   I thought it would be great learning for  hands on experience with the functionality of piston rings.  To see how well the rings work, just give a puff of air into the cylinder when assembled.</p>
<p>The crank has a 1/4&quot; hex insert for a drill, see video: <a rel="nofollow" href="https://youtu.be/-9GLqgNsoWE">https://youtu.be/-9GLqgNsoWE</a></p>
<p>I would like to challenge anyone to further make a valve system for this, that would really be cool.</p></div>
<h3 class="thing-component-header settings print-settings">Print Settings</h3>
<p class="detail-setting printer brand"><strong>Printer Brand: </strong>
                         </p><div><p>Creality</p></div>
<p></p>
                                                <p class="detail-setting printer"><strong>Printer: </strong>
                         </p><div><p>Ender 3 Pro</p></div>
<p></p>
                                                <p class="detail-setting rafts"><strong>Rafts: </strong>
                         </p><div><p>Yes</p></div>
<p></p>
                                                <p class="detail-setting supports"><strong>Supports: </strong>
                         </p><div><p>No</p></div>
<p></p>
                                                <p class="detail-setting resolution"><strong>Resolution: </strong>
                         </p><div><p>0.16</p></div>
<p></p>
                    <strong>Filament:</strong>
                    <a href="http://www.amazon.com/s?url=search-alias&amp;field-keywords=CCTREE+PLA&amp;tag=tv-auto-20" target="_blank">
                        CCTREE PLA                    </a>

                    WHITE

                        <br>                        <p class="detail-setting notes"><strong>Notes: </strong>
                        </p><div><p>Recommend 100% fill for smoother working parts.</p></div>
<h3 class="thing-component-header tips post-printing">Post-Printing</h3>
<p class="detail-title"><strong>Assembly suggestions</strong></p>
                <div><p>Assemble in this order:</p>
<ul><li>Put rings on piston (make sure the ring gap fits into the ring groove stop.</li>
<li>Insert piston into cylinder</li>
<li>Insert piston rod and secure with  piston ring while piston is partially exposed from the bottom of cylinder.</li>
<li>Complete by inserting crank assembly.  </li>
</ul></div>
</body></html>

Piston cylinder with Crank and Piston Rings

This is a remix of 11343 Single Cylinder Motor v2.0.

I increased the size so it can include two piston rings.   I thought it would be great learning for  hands on experience with the functionality of piston rings.  To see how well the rings work, just give a puff of air into the cylinder when assembled.

The crank has a 1/4" hex insert for a drill, see video: https://youtu.be/-9GLqgNsoWE

I would like to challenge anyone to further make a valve system for this, that would really be cool.

<html><head></head><body><h3 class="thing-component-header summary summary">Summary</h3>
<div><p>Hi friends,</p>
<p>In this project, I made 3-speed gearbox using my printer Tevo Tarantula and Fusion 360 software. &quot;There is no clutch in the gearbox. For this reason, gears are hardly engaged.&quot; </p>
<p>I made a video about this project assembly and testing and shared it on my youtube channel. </p>
<p>&#x2022; You can watch it here: <a rel="nofollow" href="https://www.youtube.com/watch?v=0h1hxD0WU48">https://www.youtube.com/watch?v=0h1hxD0WU48</a></p>
<h3>Part List</h3>
<p>&#x2022; 21toothCircularShaft </p>
<p>&#x2022;15toothCircularShaft</p>
<p>&#x2022;10toothCircularShaft</p>
<p>&#x2022;21toothSquareShaft</p>
<p>&#x2022;16toothSquareShaft</p>
<p>&#x2022;10toothSquareShaft</p>
<p>&#x2022;OutputShaft</p>
<p>&#x2022;InputShaft</p>
<p>&#x2022;ShaftPin (x3)</p>
<p>&#x2022;Case</p>
<p>&#x2022;InputShaftFix (x2)</p>
<p>&#x2022;InputShaftSpacer (x4)</p>
<p>&#x2022;OutputShaftFix (x2)</p>
<p>&#x2022;Arm</p>
<p>10 teeth with the smallest gear. The corresponding wheel is 20 teeth. In other words, the reduction ratio is 2. Similarly, the reduction ratio is 2. In order to increase the speed, there are gear wheels with the same number of teeth in the 3-speed option. In other words, the input and output shafts have the same speed and torque value. </p>
<p>&#x2022;   In the 1st stage, the torque doubles and the speed decreases 2 times.<br>
&#x2022;   In the second stage, torque decreases 2 times, speed increases 2 times.<br>
&#x2022;   In the third stage, torque and speed do not change.</p>
<p>&#xF0FC; The modulus of all the gears I use in this 3-speed gearbox is m = 1.5 mm. I also used spur gears. I did not use helical gears. Because in the helical gears there is also an axial force and this creates a problem for us in this project.</p>
<p>&#xF0FC; I printed spacers so that the gears match each other exactly. These and gears exactly overlap each other. </p>
<p>&#xF0FC; The bearings I used are 608zz type bearing. Inner diameter is 8 mm.</p>
<p>&#xF0FC; I used &quot; PLA+ &quot; as a material and set the nozzle temperature 205 degrees and the plate temperature 40 degrees. </p>
<p>&#xF0FC; Layer height 0.16 mm, infill 100% for moving parts, 25% for fixed parts </p>
<p>&#xF0FC; I used Simplify3d software as slicer.</p></div>
<h3 class="thing-component-header settings print-settings">Print Settings</h3>
<p class="detail-setting printer brand"><strong>Printer Brand: </strong>
                         </p><div><p>TEVO</p></div>
<p></p>
                                                <p class="detail-setting printer"><strong>Printer: </strong>
                         </p><div><p>Tarantula</p></div>
<p></p>
                                                <p class="detail-setting rafts"><strong>Rafts: </strong>
                         </p><div><p>No</p></div>
<p></p>
                                                <p class="detail-setting supports"><strong>Supports: </strong>
                         </p><div><p>No</p></div>
<p></p>
                                                <p class="detail-setting resolution"><strong>Resolution: </strong>
                         </p><div><p>0.16 mm</p></div>
<p></p>
                                                <p class="detail-setting infill"><strong>Infill: </strong>
                         </p><div><p>25%</p></div>
<p></p>
                    <strong>Filament:</strong>
                    <a href="http://www.amazon.com/s?url=search-alias&amp;field-keywords=Uzaras+%2B+PLA%2B&amp;tag=tv-auto-20" target="_blank">
                        Uzaras + PLA+                    </a>

                    Black, orange, red
</body></html>

3- Speed Gearbox / Transmission

Hi friends,

In this project, I made 3-speed gearbox using my printer Tevo Tarantula and Fusion 360 software. "There is no clutch in the gearbox. For this reason, gears are hardly engaged."

I made a video about this project assembly and testing and shared it on my youtube channel.

• You can watch it here: https://www.youtube.com/watch?v=0h1hxD0WU48

Part List
----------------------------------------------------------------------------
• 21toothCircularShaft

•15toothCircularShaft

•10toothCircularShaft

•21toothSquareShaft

•16toothSquareShaft

•10toothSquareShaft

•OutputShaft

•InputShaft

•ShaftPin (x3)

•Case

•InputShaftFix (x2)

•InputShaftSpacer (x4)

•OutputShaftFix (x2)

•Arm


10 teeth with the smallest gear. The corresponding wheel is 20 teeth. In other words, the reduction ratio is 2. Similarly, the reduction ratio is 2. In order to increase the speed, there are gear wheels with the same number of teeth in the 3-speed option. In other words, the input and output shafts have the same speed and torque value.

•	In the 1st stage, the torque doubles and the speed decreases 2 times.
•	In the second stage, torque decreases 2 times, speed increases 2 times.
•	In the third stage, torque and speed do not change.

 The modulus of all the gears I use in this 3-speed gearbox is m = 1.5 mm. I also used spur gears. I did not use helical gears. Because in the helical gears there is also an axial force and this creates a problem for us in this project.

 I printed spacers so that the gears match each other exactly. These and gears exactly overlap each other.

 The bearings I used are 608zz type bearing. Inner diameter is 8 mm.

 I used " PLA+ " as a material and set the nozzle temperature 205 degrees and the plate temperature 40 degrees.

 Layer height 0.16 mm, infill 100% for moving parts, 25% for fixed parts

 I used Simplify3d software as slicer.


<html><head></head><body><h3 class="thing-component-header summary summary">Summary</h3>
<div><p>Most modern 250 4 stroke motorcorss bikes use the magic ratio of a 76.76mm piston and 55mm stroke ratio - CRF, KXF etc. </p>
<p>This is a tapered cylinder to aid compressing the rings to fit a new piston. This specific model incorporates the head dowels as locating pins to assist in aligning the ring compressor with the barrel with a Honda CRF250R 2016 model. This may fit other years and even other models, however can be used with any 76+/-1mm piston.</p>
<p>Print in PLA, .2mm layer hight does help create a smoother bore, however I have prototyped it a .28 and it worked fine.</p>
<p>This has the Hinda motorcycles logo and CRF logo embossed on the side.</p></div>
<h3 class="thing-component-header settings print-settings">Print Settings</h3>
<p class="detail-setting printer brand"><strong>Printer Brand: </strong>
                         </p><div><p>Creality</p></div>
<p></p>
                                                <p class="detail-setting printer"><strong>Printer: </strong>
                         </p><div><p>Ender 3 Pro</p></div>
<p></p>
                                                <p class="detail-setting rafts"><strong>Rafts: </strong>
                         </p><div><p>No</p></div>
<p></p>
                                                <p class="detail-setting supports"><strong>Supports: </strong>
                         </p><div><p>No</p></div>
<p></p>
                                                <p class="detail-setting resolution"><strong>Resolution: </strong>
                         </p><div><p>0.2</p></div>
<p></p>
                                                <p class="detail-setting infill"><strong>Infill: </strong>
                         </p><div><p>15</p></div>
<p></p>
                    <strong>Filament:</strong>
                    <a href="http://www.amazon.com/s?url=search-alias&amp;field-keywords=Any+PLA&amp;tag=tv-auto-20" target="_blank">
                        Any PLA                    </a>

                    #
</body></html>

Motocross piston Compressor 250cc 77mm

Most modern 250 4 stroke motorcorss bikes use the magic ratio of a 76.76mm piston and 55mm stroke ratio - CRF, KXF etc.

This is a tapered cylinder to aid compressing the rings to fit a new piston. This specific model incorporates the head dowels as locating pins to assist in aligning the ring compressor with the barrel with a Honda CRF250R 2016 model. This may fit other years and even other models, however can be used with any 76+/-1mm piston.

Print in PLA, .2mm layer hight does help create a smoother bore, however I have prototyped it a .28 and it worked fine.

This has the Hinda motorcycles logo and CRF logo embossed on the side.

pomo turbo diesel golf 2

<html><head></head><body><h3 class="thing-component-header summary summary">Summary</h3>
<div><p>Hi everyone, </p>
<p>First of all i have a video about this project on my youtube channel. I think you should assemble it by watching the video. </p>
<p>Here is the link: <a rel="nofollow" href="https://www.youtube.com/watch?v=klcB5OxXbkE">https://www.youtube.com/watch?v=klcB5OxXbkE</a></p>
<p>I designed a 2 stroke engine model in this project. It can be completely printed with a 3d printer. You don&apos;t need any extra parts. </p>
<p>Piston diameter 25 mm and stroke 25 mm. Thus, it has a cylinder volume of 12.25 cc.<br>
The bearings I use are 608zz type and have 8 mm inner diameter. (From those used in standard stress wheels).</p>
<hr><p>IMPORTANT<br>
Some parts have 2 versions. One is in full section and the other is in half section. I have added two versions, you can print the way you want.</p>
<p>Also, in some printers, the circle shape may not be exactly as desired. For this I have also added the tolerant shape of the pins. If your printer can print a 3mm diameter circle exactly 3mm, use 3mm diameter pins. Otherwise, use 2.5 mm pins.<br>
Besides, I used glue to join the pieces together. </p>
<p>If you have any problems please leave a comment.</p></div>
<h3 class="thing-component-header settings print-settings">Print Settings</h3>
<p class="detail-setting printer brand"><strong>Printer Brand: </strong>
                         </p><div><p>TEVO</p></div>
<p></p>
                                                <p class="detail-setting printer"><strong>Printer: </strong>
                         </p><div><p>Tarantula</p></div>
<p></p>
                                                <p class="detail-setting rafts"><strong>Rafts: </strong>
                         </p><div><p>No</p></div>
<p></p>
                                                <p class="detail-setting supports"><strong>Supports: </strong>
                         </p><div><p>Yes</p></div>
<p></p>
                                                <p class="detail-setting resolution"><strong>Resolution: </strong>
                         </p><div><p>0.16</p></div>
<p></p>
                                                <p class="detail-setting infill"><strong>Infill: </strong>
                         </p><div><p>25%</p></div>
<p></p>
                    <strong>Filament:</strong>
                    <a href="http://www.amazon.com/s?url=search-alias&amp;field-keywords=uzaras+PLA%2B&amp;tag=tv-auto-20" target="_blank">
                        uzaras PLA+                    </a>
<h3 class="thing-component-header tips post-printing">Post-Printing</h3>
<div><p>You can watch the video<br><a rel="nofollow" href="https://www.youtube.com/watch?v=klcB5OxXbkE">https://www.youtube.com/watch?v=klcB5OxXbkE</a></p></div>
</body></html>

Fully 3D Printable 2 Stroke Engine Model

Hi everyone,

First of all i have a video about this project on my youtube channel. I think you should assemble it by watching the video.

Here is the link: https://www.youtube.com/watch?v=klcB5OxXbkE

I designed a 2 stroke engine model in this project. It can be completely printed with a 3d printer. You don't need any extra parts.

Piston diameter 25 mm and stroke 25 mm. Thus, it has a cylinder volume of 12.25 cc.
The bearings I use are 608zz type and have 8 mm inner diameter. (From those used in standard stress wheels).

-------------------------------------------

IMPORTANT
Some parts have 2 versions. One is in full section and the other is in half section. I have added two versions, you can print the way you want.

Also, in some printers, the circle shape may not be exactly as desired. For this I have also added the tolerant shape of the pins. If your printer can print a 3mm diameter circle exactly 3mm, use 3mm diameter pins. Otherwise, use 2.5 mm pins.
Besides, I used glue to join the pieces together.

If you have any problems please leave a comment.


Piston 3D model, more files here:<br>
<a href="https://bit.ly/2Uw6wRO" target="_blank">https://bit.ly/2Uw6wRO</a><br>
&#xA0;

Piston

Piston 3D model, more files here:
https://bit.ly/2Uw6wRO


<p>Run by just blowing air into it. Demonstration:<br>
<iframe width="593" height="370" src="//www.youtube.com/embed/_FDZzKAFSz4" frameborder="0" allowfullscreen></iframe></p>

<p>Exploded view in 3d viewer:<br>
<a href="https://skfb.ly/6LQBR" rel="external">https://skfb.ly/6LQBR</a></p>

<p>There&apos;s a LEGO compatible version of the motor:<br>
<a href="https://www.youmagine.com/designs/air-balloon-motor-for-lego" rel="external">https://www.youmagine.com/designs/air-balloon-motor-for-lego</a></p>

<p>If you like how it works, you can support me by purchasing the Pneumobile chassis:<br>
<a href="https://cults3d.com/en/3d-model/game/pneumobile-pneumatic-toy-car" rel="external">https://cults3d.com/en/3d-model/game/pneumobile-pneumatic-toy-car</a> (3d Viewer: <a href="https://skfb.ly/6LV6D" rel="external">https://skfb.ly/6LV6D</a>)</p>

<p>Extra parts needed:<br>
- M3x8 Bolts (x15)<br>
- M3 Nuts (x15)<br>
- Thin Nitrile Gloves (thumbs from M sized gloves worked the best)<br>
or Silicon (worse) or PET (not tested) ones</p>

<p>Optional parts:<br>
- M3x12 or longer bolts (2x)(for the gears)<br>
- M3 Nuts (x2)(for the gears)<br>
- 6x4mm Silicon Pipe (can be found in aquarium shops)<br>
- M5x10mm Washers (x2) (instead of printed ones)<br>
- 105ZZ Bearings (x2) (noticed no difference in performance)</p>

<p>Parts with &quot;X_&quot; in their names are optional.</p>

<p>Assembly:<br>
- Use 3d diagram as a guide: <a href="https://skfb.ly/6LQBR" rel="external">https://skfb.ly/6LQBR</a><br>
- Cut off a glove finger tip (thumbs from M sized glove worked well)<br>
- Pull it onto a Cylinder_Ring (Use Helper_Finger to leave enough height)<br>
- Connect a Piston to it with two Washers<br>
- Clamp the Cylinder_Ring between Cylinder_Plate and and Cylinder_Lid<br>
- Clip them with Helper_Clamp so they won&apos;t fall apart at once<br>
- Bolt them together to Plate_Top<br>
- Repeat for the other 2 cylinders<br>
- Insert th Crank with 2 Washers<br>
- Fix it in place with Frame_Bottom<br>
- Bolt all the parts together<br>
- Put the Valve_Inner in place<br>
- Bolt the Valve_Lid into place<br>
- The engine should be running!</p>

<p>Troubleshooting:<br>
1. Rotated freely by hand, but struggling when working - the inner valve may have too much friction against the frame (sanding the valve and the frame may help for a while).<br>
2. Jams on a certain cylinder - this glove finger may need a bit more slack.<br>
3. Isn&apos;t rotated freely by hand - gears bolted too tightly to frame (should have a bit of play), some gear teeth didn&apos;t print very well, or the whole gear printed with &quot;elephant foot&quot; and runs too tight with another gear.</p>


Balloon Powered Radial Engine

Run by just blowing air into it. Demonstration:


Exploded view in 3d viewer:
https://skfb.ly/6LQBR

There's a LEGO compatible version of the motor:
https://www.youmagine.com/designs/air-balloon-motor-for-lego

If you like how it works, you can support me by purchasing the Pneumobile chassis:
https://cults3d.com/en/3d-model/game/pneumobile-pneumatic-toy-car (3d Viewer: https://skfb.ly/6LV6D)

Extra parts needed:
- M3x8 Bolts (x15)
- M3 Nuts (x15)
- Thin Nitrile Gloves (thumbs from M sized gloves worked the best)
or Silicon (worse) or PET (not tested) ones

Optional parts:
- M3x12 or longer bolts (2x)(for the gears)
- M3 Nuts (x2)(for the gears)
- 6x4mm Silicon Pipe (can be found in aquarium shops)
- M5x10mm Washers (x2) (instead of printed ones)
- 105ZZ Bearings (x2) (noticed no difference in performance)

Parts with "X_" in their names are optional.

Assembly:
- Use 3d diagram as a guide: https://skfb.ly/6LQBR
- Cut off a glove finger tip (thumbs from M sized glove worked well)
- Pull it onto a Cylinder_Ring (Use Helper_Finger to leave enough height)
- Connect a Piston to it with two Washers
- Clamp the Cylinder_Ring between Cylinder_Plate and and Cylinder_Lid
- Clip them with Helper_Clamp so they won't fall apart at once
- Bolt them together to Plate_Top
- Repeat for the other 2 cylinders
- Insert th Crank with 2 Washers
- Fix it in place with Frame_Bottom
- Bolt all the parts together
- Put the Valve_Inner in place
- Bolt the Valve_Lid into place
- The engine should be running!

Troubleshooting:
1. Rotated freely by hand, but struggling when working - the inner valve may have too much friction against the frame (sanding the valve and the frame may help for a while).
2. Jams on a certain cylinder - this glove finger may need a bit more slack.
3. Isn't rotated freely by hand - gears bolted too tightly to frame (should have a bit of play), some gear teeth didn't print very well, or the whole gear printed with "elephant foot" and runs too tight with another gear.


<p>Demo and assembly guide: <iframe width="593" height="370" src="//www.youtube.com/embed/5G4Wwa94_aM" frameborder="0" allowfullscreen></iframe></p>

<p>Exploded view in 3d viewer: <a href="https://skfb.ly/6QL8R" rel="external">https://skfb.ly/6QL8R</a></p>

<p>Extra parts needed:<br>
- Nitrile glove<br>
- Air balloon</p>

<p>Takes 4m of filament to print (about 5h at 20mm/s on my snail of a printer).<br>
Will print a bit prettier with supports (80deg. overhang, touching buildplate) and ironing.<br>
Parts with names starting with &quot;X_&quot; are optional.</p>

<ul>
<li>You can insert one balloon into another to get thicker walls. Meant for 2-walled balloon. Idles well with one (with a flywheel), but will hardly pull any vehicle.</li>
<li>You can use metal M5 washer instead of printed one</li>
<li>Found that PLA isn&apos;t the best material for the design: isn&apos;t very slippery, and &quot;fluid&quot; (the clips stop pushing the parts together with time)</li>
</ul>


Air Balloon Motor for LEGO

Demo and assembly guide:

Exploded view in 3d viewer: https://skfb.ly/6QL8R

Extra parts needed:
- Nitrile glove
- Air balloon

Takes 4m of filament to print (about 5h at 20mm/s on my snail of a printer).
Will print a bit prettier with supports (80deg. overhang, touching buildplate) and ironing.
Parts with names starting with "X_" are optional.


You can insert one balloon into another to get thicker walls. Meant for 2-walled balloon. Idles well with one (with a flywheel), but will hardly pull any vehicle.
You can use metal M5 washer instead of printed one
Found that PLA isn't the best material for the design: isn't very slippery, and "fluid" (the clips stop pushing the parts together with time)



<p>it is a skull piston, it will be necessary to play a little on the scale of the candle and the key arm because the nesting is too tight or a little sanding :)</p>

<p>c&apos;est un piston tete de mort, il faudra jou&#xE9; un peu sur l&apos;echelle de la bougie et du bras cle car l&apos;emboitement est trop serr&#xE9; eou un peu de poncage :)</p>


piston skull zrx, xjr

it is a skull piston, it will be necessary to play a little on the scale of the candle and the key arm because the nesting is too tight or a little sanding :)

c'est un piston tete de mort, il faudra joué un peu sur l'echelle de la bougie et du bras cle car l'emboitement est trop serré eou un peu de poncage :)


Thingscanner

Some articles you might like

Ferrari Have New 3D Printed Piston Design for F1 2017 | All3DP

Students 3D Print Efficient Single-Piston Engine from Titanium | All3DP

Show Only

Looking for tag: piston
