Cross-Axis Flexure Pivot

Cross-axis flexure pivots are created by crossing flexures and connecting them with rigid segments at their ends, allowing the opposite ends to rotate relative to each other. Cross-axis flexure pivots can replace pin joints in applications where wear and/or friction need to be low or eliminated.
